Object:Based on the given sales document numbers,to display the sales item details as shown in the figure.
REPORT:ZBBST_O_AB_CALLS.

TABLES VBAP.
SELECT-OPTIONS S_VBELN FOR VBAP-VBELN.
TYPES : BEGIN OF TY_VBAP,

              VBELN TYPE VBAP-VBELN,

              POSNR TYPE VBAP-POSNR,

              KWMENG TYPE VBAP-KWMENG,

              MEINS TYPE VBAP-MEINS,

             NETWR TYPE VBAP-NETWR,

END OF TY_VBAP.

DATA : WA_VBAP TYPE TY_VBAP,

             IT_VBAP TYPE TABLE OF TY_VBAP.

DATA V1 TYPE VBAP-NETWR.

DATA V2 TYPE VBAP-NETWR.

SELECT VBELN POSNR KWMENG MEINS NETWR FROM VBAP INTO TABLE IT_VBAP WHERE VBELN IN S_VBELN.

SORT IT_VBAP BY VBELN.

LOOP AT IT_VBAP INTO WA_VBAP. AT FIRST.
WRITE ‘Hello Welcome’. ENDAT.

AT NEW VBELN.
WRITE / WA_VBAP-VBELN COLOR 4. ENDAT.

WRITE :/ WA_VBAP-POSNR,WA_VBAP-KWMENG,WA_VBAP-MEINS,WA_VBAP-NETWR. V1 = V1 + WA_VBAP-NETWR.
V2 = V2 + WA_VBAP-NETWR.

AT END OF VBELN.
WRITE :/23 ‘SUBTOTAL’,V1 COLOR 3. CLEAR V1.
ENDAT.

AT LAST.
WRITE :/20 ‘GRAND TOTAL’,V2 COLOR 5. ENDAT.

ENDLOOP.

Events in SMARTFORMS:

It’s an event which is triggered at the first record of each block.
ADV: – It’s used to display the individual headings
This is similar as at new field name in the control break statement.

Event on sort end: –

It’s an event which is triggered at the last record of each block.
ADV: – It’s used to display the subtotals.
This is similar as at end of field name in the control break statement.

Object: Based on the given sales document numbers, to display the sales document item details as shown in the below by using ‘SMARTFORMS’.

Note: – If you want to declare the select-options in the smart form then we must declare one structure with the following fields in the data dictionary & later we refer the structure in the tables tab of form interface in the smart form.

Sign -> (C, 1)
Option -> (C, 2)

SMART FORM NAME: ZBBSTE_K_LO7
FORM INTERFACE
Table
I_SVBELN LIKE ZSP_O_STR

Global definitions

TYPES

TYPES: BEGIN OF TY_VBAP,

              VBELN TYPE VBAP-VBELN,
              POSNR TYPE VBAP-POSNR,
              KWMENG TYPE VBAP-KWMENG,
              MEINS TYPE VBAP-MEINS,
             NETWR TYPE VBAP-NETWR,
END OF TY_VBAP.

Global data

Wa_vbap type ty_vbap
It_vbap type table of ty_vbap
V1 type vbap-netwr
V2 type vbap-netwr

Initialization

I_svbeln it_vbap
Wa_vbap v2
It_vbap

Select VBELN POSNR KWMENG MEINS NETWR From VBAP Into table IT_VBAP Where VBELN in I_svbeln.
LOOP AT IT_VBAP INTO WA_VBAP.
V2 = V2 + WA_VBAP-NETWR.
ENDLOOP.

Select the main window in the left panel. Right click -> create -> text.
Double click on text. Click on editor. * grand total: &v2(zc)&
Click on back. Select the main window once again. Right click -> create -> flow logic -> loop.
Double click on loop. In the data tab provide.

It_vbap into wa_vbap

In the below sort criteria block provide field name is VBELN. Select the check box ‘event on sort begin’. Select the ‘event on sort begin’ in the left panel. Right click -> create -> text.
Double click on text.

* &wa_vbap-vbeln&

Select the loop in left panel. Right click -> create -> text.
Double click on the text. Click on editor.

* &wa_vbap-posnr& &wa_vbap-kwmeng(zc)& &wa_vbap-meins& &wa_vbap-netpr(zc)&
Click on back. Select the text in left panel. Right click -> create -> flow logic -> program lines.
Double click on code in the left panel. Provide input, output parameters.

Wa_vbap v1
V1 = v1 + wa_vbap-netwr

Double click on loop in the left panel. In the sort criteria block provide field name as Ebeln and select the check box event on sort end. Select the event on sort end in left panel. Right click -> create -> text. Double click on text.

* Sub total: &v1(zc)&
Click on back. Select the text in left panel. Right click -> create -> flow logic -> program lines.
Double click on code. Implement the logic & input parameter is v1.

Clear v1.
Save, check, activate.
In the menu bar click on environment -> function module name. based on this function module we develop the print program.

TABLES VBAP.
SELECT-OPTIONS S_VBELN FOR VBAP-VBELN.
CALL FUNCTION ‘/1BCDWB/SF00000265’
TABLES
I_SVBELN = S_VBELN.

Note : Smart forms are client independent that means if we create the smart form in any one of the client, then it automatically reflected in all other clients in the same server.

Why SAP smartforms are client independent

Whenever, we activate the smart forms then it generate function module, function modules are client independent so smart form is client independent

OR
Smart forms in SAP use text editor to print the symbols, text editors are client independent so smart form is client independent.

Note : In real time for complex objects, we develop the total program in print program and transfers the
displayed data into smart form layout and print.
Here we must create one structure with the transferred fields in the data dictionary. Based on the structure we declare the work area in import tab and internal table in tables tab of form interface in the smart form layout.

Object : Based on the given company codes, to display the company codes, customer numbers and recon account by using smart forms and develop the total object in print program.

Note : In this object, we must create one structure with BUKRS,KUNNR,AKONT in SE11 transaction and based on this structure we declare the internal table in tables tab of form interface.

Structure name : ZSW_P_BBS1 (Created in se11)

SMARTFORM LAYOUT
SMARTFORM NAME : ZBBSHE_C_MA8

FORM INTERFACE:
TABLES TAB:
I_IT LIKE ZSW_P_BBS1

GLOBAL DEFINITION IN LEFT PANNEL

Global data tab
WA TYPE ZSP_O_STR1

Expand the page in left pannel
Expand the main window
Select the main windowright clickcreateflowlogicloop
Double click on loop
in data tab
Loop at I_IT into WA
Select the loop in the left pannel-> right click-> crate-> text
Double clikc on text editor
&WA-BUKRS& &WA-KUNNR& &WA-AKONT&
Click on back
Save, check and activate

in the menubar -> click on enivironment-> click on function module
Based on the function module, we develop the print program
